Home / Driver Accessories / Power Supplies / Modules / Power Supplies

Filter
BECT832N-SSOBECT832N-SSO

BECT940-SSO-3SL

Part# : BECT940-SSO-1 Categories: Driver Accessories, Power Supplies
Clear
BECT940-SSO-3SL
Featured Products
  • POSITX-3D Torque Arm Positioning System POSITX-3D Torque Arm Positioning System
  • ERGO15ATorque Reaction Arm15Nm (132.8 in-lbs)Positioning System Capable (Universal Tool Holder) ERGO50A
    Torque Reaction Arm
    50Nm (442.5 in-lbs)
    Positioning System Capable
    (Universal Tool Holder)
  • ERGO15LTorque Reaction Arm15Nm (132.8 in-lbs)Positioning System Capable (Universal Tool Holder) ERGO50L
    Torque Reaction Arm
    50Nm (442.5 in-lbs)
    Positioning System Capable
    (Universal Tool Holder)
  • DR-XTC1Transducerized Torque Control System DR-XTC1
    Transducerized Torque Control System
  • Description
  • Specifications
  • ADDITIONAL INFORMATION

Add functionality and error-proofing to your CESL(T)8 Series Delta Regis Brushless Screwdriver with the BECT940-SSO-3SL Counting Controller. This controller offers a host of options including Slow Start, Batch Counting, and OK/NG Rundown. Indication based on the screw driving cycle occurring within a predefined time window. An externally accessible I/O connection provides the user with a signal interface. Outputs are available for rundown OK, rundown NG, and batch complete. External (dry contact) switches may be wired to the inputs for enable at batch start (part in position), disable, clear (reset batch count), remote start, and remote reverse. Optional cordset for Europe and the United Kingdom are available

-3SL version of the controller has inputs available to select 3 different sequences via an external signal (i.e. PLC)

• Selectable Slow Start Speed and Time
• Large LED Display of Screw Count Values
• Externally Accessible I/O Connections
• Programmable Batch Counting with Audible Buzzer indicating batch complete
• Programmable Time Window for comparison with actual fastening cycle time – LED’s indicate OK/NG rundown cycle
• Optional Timed Auto-Reverse after the clutch trips for applications requiring back-out after fastening
• Lock to limit access to program modifications
• Works with all 32V and 40V brushless drivers**



Speeds

Hi/Lo

Input

100–240VAC, 6.3A

Output

40/32/24VDC, 360W

Dimensions

248 x 130 x 100mm (9.8 x 5.1 x 3.9")

Weight

2.5 kg (5.5 lbs)

Cordset Type

North America, Europe, United Kingdom

ADDITIONAL INFORMATION
