BESL301F Series
Electric Torque Screwdriver

(0.3-1.7 Nm)
(2.6-14.8 in-lbs)

Part# : BESL301F Categories: 0-1.0 Nm (0-8.8 in-lbs), 1.0-3.0 Nm (8.8-26 in-lbs), 120V Shut Off Clutch, 120V Shut Off Clutch, Direct Plug-in, Direct Plug-in, Electric Torque Screwdrivers & Smart Tools, In-line Screwdrivers

Start Type	Clear

BESL301F Series
Electric Torque Screwdriver
(0.3-1.7 Nm)
(2.6-14.8 in-lbs)

Description
Specifications

Clean, brushless motor technology
Dependable, long lifespan
Motor shuts off when torque setting is reached
Shut-off clutch provides excellent torque repeatability
Outperforms brush-type drivers
Plugs directly into 115VAC receptacle
Input 110–120VAC, 50/60Hz, 48W
Integral 3m power cord w/ US plug
Lever or push start models available
Right angle versions available

Class	120V Shut-off
Start Type	Lever, Push
Speed (RPM)	2000
Torque Range	2.6-14.8 in-lbs (0.3-1.7 Nm)
Input	120VAC
Drive Size	1/4" Hex
Length	245 mm (9.6 in)
Diameter	36 mm (1.4 in)
Weight	470 g (1.1 lbs)
Compliance	RoHS
