    • CESL812-ESD Series
    Electric Torque Screwdriver

    (0.10-0.98 Nm)
    (0.9-8.7 in-lbs)

    Part# : CESL812-ESD-Series Categories: , , ,

    Not sure if this product is for you?

    Test Drive

    Or Let Delta Regis Help!

    Product Application Form

    Complete your fastening system...
    CESL812-ESD SeriesElectric Torque Screwdriver(0.10-0.98 Nm)(0.9-8.7 in-lbs)
    BECT620C (Hi/Lo Spd)
    BECT820(N) (Hi/Lo Spd)
    BECT832-SSO-V4.0
    Tool Balancer DR-TB1.5K (1.1-3.3 lbs)
    This item: CESL812-ESD Series
    Electric Torque Screwdriver

    (0.10-0.98 Nm)
    (0.9-8.7 in-lbs)
    1 × BECT620C (Hi/Lo Spd)
    Cordset
    Clear
    Standard power supply for 1000 RPM model (CESL812-ESD)
    1 × BECT820(N) (Hi/Lo Spd)
    Cordset
    Clear
    Standard power supply for 500 RPM model (CESL812S-ESD)
    1 × BECT832-SSO-V4.0
    Cordset Type
    Clear
    Upgraded Power Supply - Batch Count & I/O (All Models)
    1 × Tool Balancer DR-TB1.5K (1.1-3.3 lbs) 44.00 USD

    CESL812-ESD Series Electric Torque Screwdriver

    • Precise torque control, low torque reaction
    • Quiet brushless DC motor means no carbon dust
    • Compact body design results in exceptional maneuverability and operator comfort
    • Less heat build-up and higher duty cycle capabilities than conventional brush motors
    • 3 year motor warranty
    • Screwdriver includes: torque lock sleeve, 6-pin, 2m long cable and Philips bits
    • CE, RoHS Compliant
    • Power supply required – sold separately

    Inline Electric Torque Screwdrivers provide excellent ergonomic benefits and increase efficiency to most assembly applications. Our inline electric torque controlled screwdrivers are offered in both AC direct plug-in a well as DC with external power supply and are offered in multiple torque ranges, start types & operating speeds.

    The Delta Regis CESL8 Series Premium Brushless Screwdrivers provide the ultimate combination of ergonomics, precision, performance and environmental cleanliness to the installation of fasteners. The quiet, brushless DC motor does not create the carbon dust generated by the brushes in a conventional DC motor, and its low power consumption results in a tool that runs cooler, even under demanding applications.

    Class

    32V Compact Shut-off
    Start Type

    Lever, Push
    Torque Range

    0.9-8.7 in-lbs (0.10-0.98 Nm), 1.8-8.7 in-lbs (0.2-0.98 Nm)
    Speed (RPM)

    280, 1000/700
    Style

    Inline
    Input

    32-24VDC
    Drive Size

    1/4" Hex
    Length

    185 mm (7.3 in), 230 mm (9.0 in) – CESL812P-ESD Only
    Diameter

    32 mm (1.3 in)
    Weight

    385 g (0.8 lbs), 310 g (0.7 lbs) – CESL812P-ESD Only
    Compliance

    CE / RoHS
    ESD Safe/Non ESD Safe

    ESD Safe
